| 型号 |
额定功率 (KW) |
额定电流 (A) |
电压 (V) |
产生热值 (KW) |
出水温度 |
产水量 (L/H) |
主机外形尺寸 (mm) |
主机净重 (Kg) |
循环口径 (mm) |
| GR110S-Y | 2.8 | 5.5 | 380 | 11 | 55 | 240 | 655x695x815 | 100 | 40 |
| GR180S-Y | 4.7 | 8.5 | 380 | 18 | 55 | 400 | 710x710x1015 | 180 | 40 |
| GR220S-Y | 5.5 | 10.5 | 380 | 22 | 55 | 475 | 710x710x1015 | 200 | 40 |
| GR380S-Y | 9.5 | 17.7 | 380 | 38 | 55 | 817 | 1450x710x1185 | 280 | 50 |
| GR440S-Y | 11 | 21 | 380 | 44 | 55 | 950 | 1440x800x1385 | 310 | 50 |
| GR750S-Y | 19.5 | 35.2 | 380 | 75 | 55 | 1600 | 1610x1110x1730 | 630 | 80 |
| GR860S-Y | 21.5 | 46 | 380 | 88 | 55 | 1850 | 1810x1110x1920 | 780 |
80 |
